Network Streaming
Video Resolution
3840 x 2160 (30p), 3840 x 2160 (25p), 2560 x 1440 (30p), 2560 x 1440 (25p), 1920 x 1080 (30p / 60p), 1920 x 1080 (25p / 50p), 1280 x 720 (30p / 60p), 1280 x 720 (25p / 50p)
VIDEO DATA FORMAT
MPEG-4 AVC/H.264, MPEG-H HEVC/H.265 *When [Protocol] is set to [RTMP/RTMPS], [MPEG-4 AVC/H.264] is only available.
AUDIO DATA FORMAT
AAC-LC 2ch (16bit 48 kHz)
USB Streaming
VIDEO DATA FORMAT
MJPEG, YUV420 *When [Resolution] is set to [HD(720p)], [MJPEG] is only available.
Video Resolution
3840 x 2160 (15p / 30p), 3840 x 2160 (12.5p / 25p), 1920 x 1080 (30p / 60p), 1920 x 1080 (25p / 50p), 1280 x 720 (30p), 1280 x 720 (25p)
AUDIO DATA FORMAT
LPCM 2ch (16bit 48 kHz)
Recording system (movie)
MOVIE RECORDING FORMAT (XAVC HS 4K)
3840 x 2160 (4:2:0, 10bit) (Approx.):59.94p (150 Mbps / 75 Mbps / 45 Mbps), 3840 x 2160 (4:2:0,10bit) (Approx.):50p (150 Mbps / 75 Mbps / 45 Mbps), 3840 x 2160 (4:2:0, 10bit) (Approx.):23.98p (100 Mbps / 50 Mbps / 30 Mbps), 3840 x 2160 (4:2:2, 10bit) (Approx.):59.94p (200 Mbps / 100 Mbps), 3840 x 2160 (4:2:2, 10bit) (Approx.):50p (200 Mbps / 100 Mbps), 3840 x 2160 (4:2:2, 10bit) (Approx.):23.98p (100 Mbps / 50 Mbps)
MOVIE RECORDING FORMAT (XAVC S 4K)
3840 x 2160 (4:2:0, 8bit) (Approx.):59.94p (150 Mbps), 3840 x 2160 (4:2:0, 8bit) (Approx.):50p (150 Mbps), 3840 x 2160 (4:2:0, 8bit) (Approx.):29.97p (100 Mbps / 60 Mbps), 3840 x 2160 (4:2:0, 8bit) (Approx.):25p (100 Mbps / 60 Mbps), 3840 x 2160 (4:2:0, 8bit) (Approx.):23.98p (100 Mbps / 60 Mbps), 3840 x 2160 (4:2:2, 10bit) (Approx.):59.94p (200 Mbps), 3840 x 2160 (4:2:2, 10bit) (Approx.):50p (200 Mbps), 3840 x 2160 (4:2:2, 10bit) (Approx.):29.97p (140 Mbps), 3840 x 2160 (4:2:2, 10bit) (Approx.):25p (140 Mbps), 3840 x 2160 (4:2:2, 10bit) (Approx.):23.98p (100 Mbps)
MOVIE RECORDING FORMAT (XAVC S HD)
1920 x 1080 (4:2:0, 8bit) (Approx.):119.88p (100 Mbps / 60 Mbps), 1920 x 1080 (4:2:0, 8bit) (Approx.):100p (100 Mbps / 60 Mbps), 1920 x 1080 (4:2:0, 8bit) (Approx.):59.94p (50 Mbps / 25 Mbps), 1920 x 1080 (4:2:0, 8bit) (Approx.):50p (50 Mbps / 25 Mbps), 1920 x 1080 (4:2:0, 8bit) (Approx.):29.97p (50 Mbps / 16 Mbps), 1920 x 1080 (4:2:0, 8bit) (Approx.):25p (50 Mbps / 16 Mbps), 1920 x 1080 (4:2:0, 8bit) (Approx.):23.98p (50 Mbps), 1920 x 1080 (4:2:2, 10bit) (Approx.):59.94p (50 Mbps), 1920 x 1080 (4:2:2, 10bit (Approx.):50p (50 Mbps), 1920 x 1080 (4:2:2, 10bit) (Approx.):29.97p (50 Mbps), 1920 x 1080 (4:2:2, 10bit) (Approx.):25p (50 Mbps), 1920 x 1080 (4:2:2, 10bit) (Approx.):23.98p (50 Mbps)
MOVIE RECORDING FORMAT (XAVC S-I 4K)
3840 x 2160 (4:2:2, 10bit) (Approx.):59.94p (600 Mbps), 3840 x 2160 (4:2:2, 10bit) (Approx.):50p (500 Mbps), 3840 x 2160 (4:2:2, 10bit) (Approx.):29.97p (300 Mbps), 3840 x 2160 (4:2:2, 10bit) (Approx.):25p (250 Mbps), 3840 x 2160 (4:2:2, 10bit) (Approx.):23.98p (240 Mbps)
MOVIE RECORDING FORMAT (XAVC S-I HD)
1920 x 1080 (4:2:2, 10bit) (Approx.):59.94p (222 Mbps), 1920 x 1080 (4:2:2, 10bit) (Approx.):50p (185 Mbps), 1920 x 1080 (4:2:2, 10bit) (Approx.):29.97p (111 Mbps), 1920 x 1080 (4:2:2, 10bit) (Approx.):25p (93 Mbps), 1920 x 1080 (4:2:2, 10bit) (Approx.):23.98p (89 Mbps)
Exposure control
METERING SENSITIVITY
EV-3 to EV20 (ISO100 equivalent with F2.0 lens attached)
Metering Type
1200-zone evaluative metering
Exposure Compensation
+/- 5.0 EV (1/3 EV, 1/2 EV steps selectable)
ISO Sensitivity
Still images: ISO 100 - 32000 (expandable to ISO 50 - 102400), AUTO (ISO 100 - 6400, selectable lower limit and upper limit), Movies: ISO 100 - 32000 equivalent*, AUTO (ISO 100 - 6400, selectable lower limit and upper limit) *When [SteadyShot] is set to [Standard] or [Off]. ISO 100 - 6400 equivalent when [SteadyShot] is set to [Active].
Camera Section
Sensor Type
APS-C type (23.3 x 15.5 mm), Exmor R CMOS sensor
Number of Pixels (total)
Approx. 27.0 megapixels
Number of Pixels (Effective)
Still images: Approx. 26.0 megapixels max., Movies: Approx. 19.9 megapixels max. *Number of effective pixels varies depending on attached lenses and camera settings.
Color Temperature Range
2500 K - 9900 K
Best For
Content Creation: Video & Photo for online and social media
Movie Recording Mode
XAVC S, XAVC HS, XAVC SI, S&Q
Camera Section
11 fps (Hi+)
Accessibility
Functions
Screen Reader, Focus Magnifier, Focus Map (Movie), Peaking Display, Subject Recognition in AF, Touch Focus, Touch Tracking, Touch Shutter, Touch AE, Vari-angle LCD screen, Custom function, Enlarge Menu Screen
Build/Construction
USB
USB-C (SuperSpeed USB 5 Gbps (USB 3.2)
Accessory Shoe
MI (Multi-Inteface) Shoe
LCD Screen
Advanced Touchscreen
Battery Life
Still : Approx. 610 shots (LCD), Movie: Approx. 130 min (LCD, actual recording)
DIMENSIONS
Approx. 4 5/8 x 2 3/4 x 2 1/4 inches (114.8 x 67.5 x 54.2 mm (FROM GRIP TO MONITOR))
Weight (Body Only)
Approx. 13.3 oz (Approx. 377 g)
What’s included in the Box
Camera Body: ZV-E10M2, Body cap:- ALC-B1EM, Rechargeable Battery: NP-FZ100, Accessory shoe cap, Microphone Windscreen
WI-FI
Yes (IEEE 802.11a/b/g/n/ac (2.4 GHz band/5 GHz band))
Focus system
FOCUS POINT
Still images: Max. 759 points (phase-detection AF), Movies: Max. 495 points (phase-detection AF)
Other Features
AF Level for Crossing. (Still), AF Track for Speed Changes. (Still), AF Subj. Shift Sensitivity (Movie), AF Transition Speed (Movie), Switch V/H AF Area, AF Area Regist., Circ. of Focus Point, Focus Map (Movie), AF Assist (Movie)
Focus Sensitivity Range
EV-3 to EV20 (ISO100 equivalent with F2.0 lens attached)
Recognition Target (Still images)
Human, Animal, Bird
Recognition Target (Movies)
Human, Animal, Bird
Focus Type
Fast Hybrid AF (phase-detection AF / contrast-detection AF)
Recording (still images)
Recording Format
JPEG (DCF Ver. 2.0, Exif Ver. 2.32, MPF Baseline compliant), HEIF (MPEG-A MIAF compliant), RAW (Sony ARW 5.0 format compliant)
Image Size (pixels) [3:2]
APS-C L: 6192 x 4128 (26 M), M: 4384 x 2920 (13 M), S: 3104 x 2064 (6.4 M)
Other Features
Other Features
Product Showcase Set, Background Defocus, Soft Skin Effect, Creative Look, Custom function, Picture Profile, Time-lapse, Cinematic Vlog Setting, My Image Style, Vertical Display
CLEAR IMAGE ZOOM (STILL IMAGES)
Approx. 2x
CLEAR IMAGE ZOOM (MOVIES)
Approx. 1.5x (4K), Approx. 2x (HD)
Power
USB Power Supply
Yes (Available with USB Type-C Terminal. USB Power Delivery compatible)
Supplied Battery
One rechargeable battery pack NP-FZ100
Battery Life (Movie, actual recording)
Approx. 130 min (LCD monitor) (CIPA standard) *Indication recording time, which is defined by repeating the cycle: Power on, start recording, zoom , stand-by and power off.
Battery Life (Still Images)
Approx. 610 shots (LCD monitor) (CIPA standard) *The LCD screen is turned on, shot once every 30 seconds, operate zoom alternately between W and T ends, flash strobe once every two times, turn power off and on once every ten times.
Internal Battery Charge
Yes (Available with USB Type-C Terminal. USB Power Delivery compatible)
Power consumption with LCD screen
Still images: Approx. 3.2 W (with E PZ 16-50mm F3.5-5.6 OSS II lens attached), Movies: Approx. 5.0 W (with E PZ 16-50mm F3.5-5.6 OSS II lens attached)
Interface
HDMI OUTPUT
HDMI micro connector (Type-D), 3840 x 2160 (59.94p / 50p / 29.97p / 25p / 23.98p) / 1920 x 1080n(59.94p / 50p / 23.98p) / 1920 x 1080 (59.94i / 50i), YCbCr 4:2:2 10bit / RGB 8bit
Multi Interface Shoe
Yes (with Digital Audio Interface) *Sony accessories for the Accessory Shoe can be attached.
Bluetooth
Yes (Bluetooth Standard Ver. 4.2 (2.4 GHz band))
Headphone Terminal
Yes (3.5 mm Stereo minijack)
Mic Terminal
Yes (3.5 mm Stereo minijack)
PC Interface
Mass-storage / MTP
Wireless LAN (Built-In)
Yes (Wi-Fi Compatible, IEEE 802.11a/b/g/n/ac (2.4 GHz band/5 GHz band))
*(Configuration method/Access method) WPS or manually/infrastructure mode. When connecting to smartphones, the camera can always work as a base without a wireless access point. (Security: WEP/WPA-PSK/WPA2-PSK/WPA3-SAE)
**Models sold in some countries/regions support IEEE 802.11b/g/n (2.4GHz) wireless LAN only
Remote Control (Wireless)
Yes (Bluetooth remote control)
Functions
Send to smartphone, Remote control via smartphone, Remote Shooting
USB Type-C Terminal
Yes (SuperSpeed USB 5 Gbps (USB 3.2) compatible)
Drive
Continuous Drive Speed (approx. max.)
Hi+: 11 fps *Varies according to shooting conditions or memory card used
Pixel Shift Multi Shooting
-
NO. OF FRAME RECORDABLE (APPROX.)
JPEG Extra fine L: 143 frames, JPEG Fine L: over 1000 frames, JPEG Standard L: over 1000 frames, RAW: 59 frames, RAW & JPG: 44 frames, RAW (Lossless Compressed): 22 frames, RAW (Lossless Compressed) & JPEG: 17 frames *Varies according to shooting conditions or memory card used
