Recording (still images)
Recording Format
JPEG (DCF Ver. 2.0, Exif Ver. 2.32, MPF Baseline compliant), HEIF (MPEG-A MIAF compliant), RAW (Sony ARW 4.0 format compliant)
Image Size (pixels) [3:2]
35mm full frame L: 9504 x 6336 (60 M), M: 6240 x 4160 (26 M), S: 4752 x 3168 (15 M), APS-C M: 6240 x 4160 (26 M), S: 4752 x 3168 (15 M)
Image Size (pixels) [16:9]
35mm full frame L: 9504 x 5344 (51 M), M: 6240 x 3512 (22 M), S: 4752 x 2672 (13 M), APS-C M: 6240 x 3512 (22 M), S: 4752 x 2672 (13 M)
Image Quality Modes
RAW (Compressed / Lossless Compressed (L / M / S) / Uncompressed), JPEG (Extra fine / Fine / Standard / Light), HEIF (4:2:0 / 4:2:2) (Extra fine / Fine / Standard / Light), RAW & JPEG, RAW & HEIF
Picture Profile
Yes (Off / PP1-PP11) Parameters: Black level, Gamma (Movie, Stil l, S-Cinetone, Cine1-4, ITU709, ITU709 [800%], S-Log2, S-Log3, H LG, HLG1-3), Black Gamma, Knee, Color Mode, Saturation, Color Phase, Color Depth, Detail, Copy, Reset
Dynamic Range Functions
Off, Dynamic Range Optimizer
Creative Look
ST, PT, NT, VV, VV2, FL, IN, SH, BW, SE, Custom Look (1-6)
Image size (pixels) [4:3]
35mm full frame L: 8448 x 6336 (54 M), M: 5552 x 4160 (23 M), S: 4224 x 3168 (13 M), APS-C M: 5552 x 4160 (23 M), S: 4224 x 3168 (13 M)
Image size (pixels) [1:1]
35mm full frame L: 6336 x 6336 (40 M), M: 4160 x 4160 (17 M), S: 3168 x 3168 (10 M), APS-C M: 4160 x 4160 (17 M), S: 3168 x 3168 (10 M)
Color Space
sRGB standard (with sYCC gamut), Adobe RGB standard and Re c. ITU-R BT.2100 standard (BT.2020 gamut).
Recording (movie)
Audio Recording Format
LPCM 2ch (48kHz 16bit), LPCM 2ch (48kHz 24bit), LPCM 4ch (48kHz 24bit), MPEG-4 AAC-LC 2ch
Color Space
Rec. ITU-R BT.2100 standard compatible (BT.2020 gamut)
Movie Functions
Audio Level Display, Audio Rec Level, PAL/NTSC Selector, Proxy Recording (1280 x 720 (Approx. 6 Mbps), 1920 x 1080 (Approx. 9 Mbps), 1920 x 1080 (Approx. 16 Mbps)), TC/UB, Auto Slow Shutte r, Gamma Disp. Assist, RAW Output(HDMI)
Picture Profile
Yes (Off / PP1-PP11) Parameters: Black level, Gamma (Movie, Stil l, S-Cinetone, Cine1-4, ITU709, ITU709 [800%], S-Log2, S-Log3, H LG, HLG1-3), Black Gamma, Knee, Color Mode, Saturation, Color Phase, Color Depth, Detail, Copy, Reset
Recording Format
XAVC S, XAVC HS
Video Compression
XAVC S: MPEG-4 AVC/H.264,XAVC HS: MPEG-H HEVC/H.265
MOVIE RECORDING SYSTEM (XAVC S 4K)
3840 x 2160 (4:2:0, 8bit, NTSC) (Approx.): 60p (150 Mbps), 3 0p (100 Mbps / 60 Mbps) 5 , 24p (100 Mbps / 60 Mbps), 3840 x 2160 (4:2:0, 8bit, PAL) (Approx.): 50p (150 Mbps), 25p (100 Mbp s / 60 Mbps),3840 x 2160 (4:2:2, 10bit, NTSC) (Approx.): 60p (200 Mbps), 30p (140 Mbps), 24p (100 Mbps), 3840 x 2160 (4:2:2, 10bit, PAL) (Approx.): 50p (200 Mbps), 25p (140 Mbps)
MOVIE RECORDING SYSTEM (XAVC S HD)
1920 x 1080 (4:2:0, 8bit, NTSC) (Approx.): 120p (100 Mbps / 60 M bps), 60p (50 Mbps / 25 Mbps), 30p (50 Mbps / 16 Mbps), 24p (50 Mbps),1920 x 1080 (4:2:0, 8bit, PAL) (Approx.): 100p (100 Mbps / 60 Mbps), 50p (50 Mbps / 25 Mbps), 25p (50 Mbps / 16 Mbps),1920 x 1080 (4:2:2, 10bit, NTSC) (Approx.): 60p (50 Mbp s), 30p (50 Mbps), 24p (50 Mbps),1920 x 1080 (4:2:2, 10bit, PAL) (Approx.):50p (50 Mbps), 25p (50 Mbps)
Creative Look
ST, PT, NT, VV, VV2, FL, IN, SH, BW, SE, Custom Look (1-6)
MOVIE RECORDING SYSTEM (XAVC HS 4K)
3840 x 2160 (4:2:0, 10bit, NTSC) (Approx.): 60p (150 Mbps / 75 M bps / 45 Mbps), 24p (100 Mbps / 50 Mbps / 30 Mbps), 3840 x 2160 (4:2:0, 10bit, PAL) (Approx.): 50p (150 Mbps / 75 Mbps / 45 Mbps), 3840 x 2160 (4:2:2, 10bit, NTSC) (Approx.): 60p (200 Mb ps / 100 Mbps), 24p (100 Mbps / 50 Mbps), 3840 x 2160 (4: 2:2, 10bit, PAL) (Approx.)): 50p (200 Mbps / 100 Mbps)
MOVIE RECORDING SYSTEM (XAVC HS 8K)
7680 x 4320 (4:2:0, 10bit, NTSC) (Approx.): 24p (400 Mbps / 200 Mbps) , 7680 x 4320 (4:2:0, 10bit, PAL) (Approx.): 25p (400 M bps / 200 Mbps)]
MOVIE RECORDING SYSTEM (XAVC S-I 4K)
3840 x 2160 (4:2:2, 10bit, NTSC) (Approx.): 60p (600 Mbps), 30p (300 Mbps), 24p (240 Mbps), 3840 x 2160 (4:2:2, 10bit, P AL) (Approx.): 50p (500 Mbps), 25p (250 Mbps)
MOVIE RECORDING SYSTEM (XAVC S-I HD)
1920 x 1080 (4:2:2, 10bit, NTSC) (Approx.): 60p (222 Mbps), 30 p (111 Mbps), 24p (89 Mbps),1920 x 1080 (4:2:2, 10bit, PAL) (Approx.): 50p (185 Mbps), 25p (93 Mbps)
SLOW & QUICK MOTION (SHOOTING FRAME RATE)
NTSC mode: 1fps,2fps,4fps,8fps,15fps,30fps,60fps,120fps, PAL mode: 1fps,2fps,3fps,6fps,12fps,25fps,50fps,100fps
Focus
Focus Area
Wide / Zone / Center Fix / Spot / Expand Spot / Tracking
Focus Mode
AF-A (Automatic AF), AF-S (Single-shot AF), AF-C (Continuous A F), DMF (Direct Manual Focus), Manual Focus
Focus Type
Fast Hybrid AF (phase-detection AF / contrast-detection AF)
AF illuminator
Yes (with Built-in LED type)
AF Illuminator range
Approx. 0.3 m - approx. 3.0 m (with FE 28-70 mm F3.5-5.6 OSS le ns attached)
FOCUS POINT
35mm full frame: 693 points (phase-detection AF), APS-C mode wi th FF lens: 693 points (phase-detection AF), with APS-C lens: 567 points (phase-detection AF) / 25 points (contrast-detection AF)
Focus Sensitivity Range
EV-4 to EV20 (ISO100 equivalent with F2.0 lens attached)
Focus Sensor
Exmor R CMOS sensor
Other Features
Predictive control, Focus lock, AF Track Sens. (Still), AF Subj. Shift Sensitivity (Movie), AF Transition Speed (Movie), Switch V/H AF Ar ea, AF Area Regist., Circ. of Focus Point, Focus Map (Movie), AF Assist (Movie)
Eye AF / Subject Recognition AF
Human (Right/Left Eye Select) / Animal (Right/Left Eye Select) / Bir d / Insect / Car・Train / Airplane
Exposure
Exposure Compensation
+/- 5.0EV (1/3 EV, 1/2 EV steps selectable)
AE Lock
Locked when shutter button is pressed halfway. Available with AE l ock button. (On/Off/Auto)
Exposure Bracketing
Bracket: Cont., Bracket: Single, 2/3/5/7/9 frames selectable. (Ambi ent light, Flash light)
EXPOSURE MODES
AUTO (iAuto), Programmed AE (P), Aperture priority (A), Shutter-s peed priority (S), Manual (M), Movie (Programmed AE (P) / Apertur e priority (A) / Shutter-speed priority (S) / Manual (M) / Flexible Ex p. Mode), Slow & Quick Motion (Programmed AE (P) / Aperture pri ority (A) / Shutter-speed priority (S) / Manual (M) / Flexible Exp. Mo de)
ISO Sensitivity (Recommended Exposure Index)
Still images: ISO 100-32000 (ISO numbers up from ISO 50 to ISO 102400 can be set as expanded ISO range.), AUTO (ISO 100-128 00, selectable lower limit and upper limit), Movies: ISO 100-32000 equivalent, AUTO (ISO 100-12800, selectable lower limit and uppe r limit)
Metering Mode
Multi-segment, Center-weighted, Spot (Standard / Large), Entire Sc reen Avg., Highlight
METERING SENSITIVITY
EV-3 to EV20 (ISO100 equivalent with F2.0 lens attached)
Metering Sensor
Exmor R CMOS sensor
Metering Type
1200-zone evaluative metering
Drive
Self-timer
10 s delay / 5 s delay / 2 s delay / Continuous self-time / Bracketing self-timer / Self-timer (Movie)
Continuous Drive Speed (approx. max.)
Continuous shooting: Hi+: 10 fps, Hi: 8 fps, Mid: 6 fps, Lo: 3 fps
DRIVE MODES
Single Shooting, Continuous shooting (Hi+/Hi/Mid/Lo selectable), S elf-timer,Self-timer (Cont.), Bracket: Single, Bracket: Cont., Focus Bracket, White Balance bracket, DRO bracket
No. of recordable frames (approx.)
JPEG Extra fine L: over 1000 frames, JPEG Fine L: over 1000 fram es, JPEG Standard L: over 1000 frames, RAW: 583 frames, RAW & JPEG: 184 frames, RAW (Lossless Compressed): 547 frames, R AW (Lossless Compressed) & JPEG: 159 frames, RAW (Uncompr essed): 135 frames, RAW (Uncompressed) & JPEG: 88 frames
Pixel Shift Multi Shooting
Yes (4 shots / 16 shots)
