Recording System
Location information Link from smartphone
Yes
Media
Memory Stick PRO Duo, Memory Stick PRO-HG Duo, Memory Stick Micro (M2), SD memory card, SDHC memory card (UHS-I/II compliant), SDXC memory card (UHS-I/II compliant), microSD memory card, microSDHC memory card, microSDXC memory card
Memory Card Slot
SLOT1: Slot for SD (UHS-I/II compliant) memory card, SLOT2: Multi slot for Memory Stick Duo™/SD (UHS-I compliant) memory card
Recording mode on 2 memory cards
Simult. Rec (Still), Simult. Rec (Movie), Simult. Rec (Still/,Movie), Sort (JPEG/RAW), Sort (Still/Movie), Auto Switch Media (On/Off), Copy
Recording (movie)
Audio Recording Format
XAVC S: LPCM 2ch, AVCHD: Dolby® Digital (AC-3) 2ch, Dolby® Digital Stereo Creator
Color Space
xvYCC standard (x.v.Color when connected via HDMI cable) compatible with TRILUMINOS Color
Creative Style
Standard, Vivid, Neutral, Clear, Deep, Light, Portrait, Landscape, Sunset, Night Scene, Autumn leaves, Black & White, Sepia, Style Box (1-6), (Contrast (-3 to +3 steps), Saturation (-3 to +3 steps), Sharpness (-3 to +3 steps))
Image Size (pixels), NTSC
XAVC S 4K: 3840 x 2160 (30p, 100 M), 3840 x 2160 (24p, 100 M), 3840 x 2160 (30p, 60 M), 3840 x 2160 (24p, 60 M), XAVC S HD: 1920 x 1080 (120p, 100M), 1920 x 1080 (120p, 60M), 1920 x 1080 (60p, 50M), 1920 x 1080 (30p, 50M), 1920 x 1080 (24p, 50M), 1920 x 1080 (60p, 25M), 1920 x 1080 (30p, 16M), AVCHD: 1920 x 1080 (60i, 24M, FX), 1920 x 1080 (60i, 17M, FH)
Image Size (pixels), PAL
XAVC S 4K: 3840 x 2160 (25p, 100M), 3840 x 2160 (25p, 60M), XAVC S HD:1920 x 1080 (100p, 100M), 1920 x 1080 (100p, 60M), 1920 x 1080 (50p, 50M), 1920 x 1080 (25p, 50M), AVCHD:1920 x 1080 (50i, 24M, FX), 1920 x 1080 (50i, 17M, FH)
Movie Functions
Audio Level Display, Audio Rec Level, PAL/NTSC Selector, Yes (1280 x 720 (Approx.9 Mbps)), TC/UB (TC Preset/UB Preset/TC Format/TC Run/TC Make/UB Time Rec), Auto Slow Shutter, REC Control, Clean HDMI Info. (ON/OFF selectable), Gamma Disp. Assist
Picture Effect
Posterization (Color), Posterization (B/W), Pop Color, Retro Photo, Partial Color (R/G/B/Y), High Contrast Monochrome, Toy Camera (Normal/Cool/Warm/Green/Magenta), Soft High-key
Picture Profile
Yes (Off/PP1-PP10) Parameters: Black level, Gamma (Movie, Still, Cine1-4, ITU709, ITU709 [800%], S-Log2, S-Log3, HLG, HLG1-3), Black Gamma, Knee, Color Mode, Saturation, Color Phase, Color Depth, Detail, Copy, Reset
Recording Format
XAVC S, AVCHD format Ver. 2.0 compliant
Slow & quick motion (recording frame rate & image size)
NTSC mode: 1920x1080 (60p, 30p, 24p), PAL mode: 1920x1080 (50p, 25p)
Slow & quick motion (shooting frame rate)
NTSC mode: 1fps, 2fps, 4fps, 8fps, 15fps, 30fps, 60fps, 120fps, PAL mode: 1fps, 2fps, 3fps, 6fps, 12fps, 25fps, 50fps, 100fps
Video Compression
XAVC S: MPEG-4 AVC/H.264, AVCHD: MPEG-4 AVC/H.264
Clean HDMI output
3840 x 2160 (25p), 1920 x 1080 (50p), 1920 x 1080 (50i), 1920 x 1080 (24p), 1920 x 1080 (60p), 1920 x 1080 (60i), 3840 x 2160 (30p), 3840 x 2160 (24p), YCbCr 4:2:2 8-bit / RGB 8-bit
Recording (still images)
Color Space
sRGB standard (with sYCC gamut) and Adobe RGB standard, compatible with TRILUMINOS™ Color
Creative Style
Standard, Vivid, Neutral, Clear, Deep, Light, Portrait, Landscape, Sunset, Night Scene, Autumn leaves, Black & White, Sepia, Style Box (1-6), (Contrast (-3 to +3 steps), Saturation (-3 to +3 steps), Sharpness (-3 to +3 steps))
Dynamic Range Functions
Off, Dynamic Range Optimizer (Auto/Level (1-5)), Auto High Dynamic Range (Auto Exposure Difference, Exposure Difference Level (1-6 EV, 1.0 EV step))
Image Quality Modes
RAW, RAW & JPEG (Extra fine, Fine, Standard), JPEG (Extra fine, Fine, Standard)
Image Size (pixels) [16:9]
35 mm full frame L: 6000 x 3376 (20 M), M: 3936 x 2216 (8.7M), S: 3008 x 1688 (5.1M), APS-C L: 3936 x 2216 (8.7M), M: 3008 x 1688 (5.1M), S: 1968 x 1112 (2.2M)
Image Size (pixels) [3:2]
35 mm full frame L: 6000 x 4000 (24M), M: 3936 x 2624 (10M), S: 3008 x 2000 (6.0M), APS-C L: 3936 x 2624 (10M), M: 3008 x 2000 (6.0M), S: 1968 x 1312 (2.6M)
Image Size (pixels) [Sweep Panorama]
-
Picture Effect
8 types: Posterization (Color), Posterization (B/W), Pop Color, Retro Photo, Partial Color (R/G/B/Y), High Contrast Monochrome, Toy Camera (Normal/Cool/Warm/Green/Magenta), Soft High-key , Rich-tone Monochrome
Picture Profile
Yes (Off/PP1-PP10) Parameters: Black level, Gamma (Movie, Still, Cine1-4, ITU709, ITU709 [800%], S-Log2, S-Log3, HLG, HLG1-3), Black Gamma, Knee, Color Mode, Saturation, Color Phase, Color Depth, Detail, Copy, Reset
Recording Format
JPEG (DCF Ver. 2.0, Exif Ver.2.31, MPF Baseline compliant), RAW (Sony ARW 2.3 format)
Other Features
Clear Image Zoom
Still images: Approx. 2x, Movies: Approx. 1.5x (4K), Approx. 2x (HD)
Digital Zoom
Smart zoom (Still images): 35 mm full frame: M: approx 1.5x, S: approx 2x, APS-C: M: approx 1.3x, S: approx 2x, Digital zoom (Still images): 35 mm full frame: L: approx 4x, M: approx 6.1x, S: approx 8x, APS-C: L: approx 4x, M: approx 5.2x, S: approx 8x,Digital zoom (Movie): 35 mm full frame: approx 4x, APS-C: approx 4x
Face Detection
Modes: Face Priority in AF (On/Off), Face Priority in Multi Metering (On/Off), Regist. Faces Priority (On/Off), Face registration, Max. number of detectable: 8
Others
Touch Focus: Yes (Available with LCD monitor or Viewfinder operation), ISO AUTO Min. SS, Bright Monitoring, Set File Name, FTP Transfer Func., Help guide, Area Setting, Shop Front Mode, Video Light Mode, Zoom Ring Rotate
PlayMemories Camera Apps™
-
Self-Portrait Self-Timer
-
LCD Screen
Adjustable Angle
Up by approx. 107 degrees, Down by approx. 41 degrees
Brightness Control
Manual (5 steps between -2 and +2), Sunny Weather mode
Display Content
Graphic Display, Display All Info, No Disp. Info, Digital Level Gauge, Histogram, For viewfinder, Monitor Off
Focus Magnifier
Yes (35mm full frame: 5.9x, 11.7x, APS-C: 3.8x, 7.7x)
Monitor Type
2.95 inch (3.0-type) wide type TFT
Number of Dots
921,600 dots
Others
Grid Line (Rule of 3rds Grid/Square Grid/Diag. + Square Grid/Off), Movie Marker (Center/Aspect/Safety Zone/Guideframe)
Peaking MF
Yes (Level setting: High/Mid/Low/Off, Color: White/Red/Yellow)
Real-time Image Adjustment Display (LCD)
On/Off
Zebra
Yes (selectable level + range or lower limit as custom setting)
Display Selecter (Finder/LCD)
Yes (Auto/Manual)
Interface
HD Output
HDMI micro connector (Type-D),BRAVIA Sync (Control for HDMI), PhotoTV HD, 4K movie output/4K still image PB
Bluetooth®
Yes (Bluetooth Standard Ver. 4.1 (2.4 GHz band))
Headphone Terminal
Yes (3.5 mm Stereo minijack)
Mic Terminal
Yes (3.5 mm Stereo minijack)
Multi/Micro USB terminal
Yes
NFC™
Yes (NFC forum Type 3 Tag compatible), One-touch remote, One-touch sharing
PC Interface
Mass-storage, MTP, PC remote
Vertical Grip Connector
Yes
Wireless LAN (Built-In)
Wi-Fi Compatible, IEEE 802.11b/g/n (2.4 GHz band), View on Smartphone, Remote control via Smartphone, Send to Computer, View on TV
Smart Accessory Terminal 2
-
Auto-lock Accessory Shoe
-
USB Type-C™ Terminal
Yes (SuperSpeed USB (USB 3.1 Gen 1) compatible)
Focus
Focus Area
Wide (693 points (phase-detection AF), 425 points (contrast-detection AF)) / Zone / Center / Flexible Spot (S/M/L) /Expanded Flexible Spot/ Lock-on AF (Wide / Zone / Center / Flexible Spot (S/M/L)/Expanded Flexible Spot)
Focus Mode
AF-A (Automatic AF), AF-S (Single-shot AF), AF-C (Continuous AF), DMF (Direct Manual Focus), Manual Focus
Focus Type
Fast Hybrid AF (phase-detection AF/contrast-detection AF)
AF illuminator
Yes (with built-in LED type)
AF Illuminator range
Approx. 0.3 m - approx. 3.0 m (with FE 28-70 mm F3.5-5.6 OSS attached)
FOCUS POINT
35 mm full frame: 693 points (phase-detection AF), APS-C mode with full frame lens: 299 points (phase-detection AF), with APS-C lens: 221 points (phase-detection AF) / 425 points (contrast-detection AF)
Focus Sensitivity Range
EV-3 to EV 20 (ISO 100 equivalent with F2.0 lens attached)
Focus Sensor
Exmor R® CMOS sensor
Focus type with LA-EA3 (Sold separately)
selectable (phase-detection, contrast-detection)
Other Features
Eye-start AF (only with LA-EA2 or LA-EA4 attached (sold separately)), Lock-on AF, Eye AF, AF micro adjustment with LA-EA2 or LA-EA4 (sold separately), Predictive control, Focus lock, AF Track Sens, Swt. V/H AF Area, AF Area Regist.
Flash Control
External Flash Compatibility
Sony α System Flash compatible with Multi Interface Shoe, attach the shoe adapter for flash compatible with Auto-lock accessory shoe
Flash Bracketing
3/5/9 frames selectable. With 3 or 5 frames, in 1/3, 1/2, 2/3, 1.0, 2.0, 3.0 EV increments, with 9 frames, in 1/3, 1/2, 2/3, 1.0 EV increments.
Flash compensation
+/- 3.0 EV (switchable between 1/3 and 1/2 EV steps)
Flash Modes
Flash off, Autoflash, Fill-flash, Slow Sync., Rear Sync., Red-eye reduction (on/off selectable), Wireless, Hi-speed sync.
Wireless Control
Yes (Light signal: Available with Fill-flash, Slow Sync., Hi-speed sync. /Radio signal: Available with Fill-flash, Rear Sync., Slow Sync., Hi-speed sync.)
Exposure
Exposure Compensation
+/- 5.0EV (1/3 EV, 1/2 EV steps selectable) (with exposure compensation dial: +/- 3EV (1/3 EV steps))
AE Lock
Locked when shutter button is pressed halfway. Available with AE lock button (On/Off/Auto)
Exposure Bracketing
Bracket: Cont., Bracket: Single, 3/5/9 frames selectable. With 3 or 5 frames, in 1/3, 1/2, 2/3, 1.0, 2.0, or 3.0 EV increments, with 9 frames, in 1/3, 1/2, 2/3, or 1.0 EV increments
EXPOSURE MODES
AUTO (iAuto), Programmed AE (P), Aperture priority (A), Shutter-speed priority (S), Manual (M), Movie (Programmed AE (P) / Aperture priority (A) / Shutter-speed priority (S) / Manual (M) ), Slow & Quick Motion (Programmed AE (P) / Aperture priority (A) / Shutter-speed priority (S) / Manual (M) ), Scene Selection
ISO Sensitivity (Recommended Exposure Index)
Still images: ISO 100-51200 (ISO numbers from ISO 50 to ISO 204800 can be set as expanded ISO range.), AUTO (ISO 100-12800, selectable lower limit and upper limit), Movies: ISO 100-51200 equivalent (ISO numbers up to ISO 102400 can be set as expanded ISO range.), AUTO (ISO 100-12800, selectable lower limit and upper limit)
Metering Mode
Multi-segment, Center-weighted, Spot, Spot Standard/Large, Entire Screen Avg., Highlight
METERING SENSITIVITY
EV -3 to EV 20 (at ISO100 equivalent with F2.0 lens attached)
Metering Sensor
Exmor R® CMOS sensor
Metering Type
1200-zone evaluative metering
Scene Selection
Portrait, Sports Action, Macro, Landscape, Sunset, Night Scene, Night Portrait
Drive
Self-timer
10 sec. delay/5 sec. delay/2 sec. delay/Continuous self-timer (3 frames after 10 sec. delay/5 frames after 10 sec. delay/3 frames after 5 sec. delay/5 frames after 5 sec. delay/3 frames after 2 sec. delay/5 frames after 2 sec. delay)/Bracketing self-timer
Continuous Drive Speed (approx. max.)
Continuous shooting: Hi+: max. 10 fps, Hi: max. 8 fps, Mid: max. 6fps, Lo: max. 3 fps
DRIVE MODES
Single Shooting, Continuous shooting (Hi+/Hi/Mid/Lo selectable), Self-timer, Self-timer (Cont.), Bracket: Single, Bracket: Cont., White Balance bracket, DRO bracket
No. of recordable frames (approx.)
JPEG Extra fine L: 163 frames, JPEG Fine L: 172 frames, JPEG Standard L: approx. 177 frames, RAW: 89 frames, RAW & JPG: 79 frames, RAW (Uncompressed): 40 frames, RAW (Uncompressed) & JPG: 36 frames
