Recording (movie)
Audio Recording Format
XAVC S: LPCM 2ch, AVCHD: Dolby® Digital (AC-3) 2ch, Dolby® Digital Stereo Creator
Color Space
xvYCC standard (x.v.Color when connected via HDMI cable) compatible with TRILUMINOS Color
Creative Style
Standard, Vivid, Portrait, Landscape, Sunset, Black & white, Sepia, (Contrast (-3 to +3 steps), Saturation (-3 to +3 steps), Sharpness (-3 to +3 steps))
HDMI OUTPUT
3840 x 2160 (30p), 3840 x 2160 (25p), 3840 x 2160 (24p), 1920 x 1080 (60p), 1920 x 1080 (60i), 1920 x 1080 (50p), 1920 x 1080 (50i), 1920 x 1080 (24p), YCbCr 4:2:2 8 bit / RGB 8 bit
Image Size (pixels), NTSC
XAVC S 4K:3840 x 2160 (30p, 100M), 3840 x 2160 (24p, 100M), 3840 x 2160 (30p, 60M), 3840 x 2160 (24p, 60M), XAVC S HD:1920 x 1080 (120p, 100M), 1920 x 1080 (120p, 60M), 1920 x 1080 (60p, 50M), 1920 x 1080 (30p, 50M), 1920 x 1080 (24p, 50M), 1920 x 1080 (60p, 25M), 1920 x 1080 (30p, 16M), AVCHD:1920 x 1080 (60i, 24M, FX), 1920 x 1080 (60i, 17M, FH)
Image Size (pixels), PAL
XAVC S 4K:3840 x 2160 (25p, 100M), 3840 x 2160 (25p, 60M), XAVC S HD:1920 x 1080 (100p, 100M), 1920 x 1080 (100p, 60M), 1920 x 1080 (50p, 50M), 1920 x 1080 (25p, 50M), 1920 x 1080 (50p, 25M), 1920 x 1080 (25p, 16M), AVCHD:1920 x 1080 (50i, 24M, FX), 1920 x 1080 (50i, 17M, FH)
Movie Functions
Audio Level Display, Audio Rec Level, PAL/NTSC Selector, Proxy Recording (1280 x 720 (Approx.9 Mbps)), Auto Slow Shutter, Clean HDMI Info. (ON/OFF selectable)
Picture Effect
Posterization (Color), Posterization (B/W), Pop Color, Retro Photo, Partial Color (R/G/B/Y), High Contrast Monochrome, Toy Camera (Normal/Cool/Warm/Green/Magenta), Soft High-key
Recording Format
XAVC S, AVCHD format Ver. 2.0 compliant
Slow & quick motion (recording frame rate & image size)
NTSC mode: 1920x1080 (60p, 30p, 24p), PAL mode: 1920x1080 (50p, 25p)
Slow & quick motion (shooting frame rate)
NTSC mode: 1 fps, 2 fps, 4 fps, 8 fps, 15 fps, 30 fps, 60 fps, 120 fps, PAL mode: 1fps,2fps,3fps,6fps,12fps,25fps,50fps,100fps
Video Compression
XAVC S: MPEG-4 AVC/H.264, AVCHD: MPEG-4 AVC/H.264
Recording (still images)
Color Space
sRGB standard (with sYCC gamut) and Adobe RGB standard compatible with TRILUMINOS Color
Creative Style
Standard, Vivid, Portrait, Landscape, Sunset, Black & white, Sepia, (Contrast (-3 to +3 steps), Saturation (-3 to +3 steps), Sharpness (-3 to +3 steps))
Dynamic Range Functions
Off, Dynamic Range Optimizer (Auto/Level (1-5)), Auto High Dynamic Range (Auto Exposure Difference, Exposure Difference Level (1-6 EV, 1.0 EV step))
IMAGE SIZE (PIXELS) [1:1]
L: 4000 x 4000 (16M), M: 2832 x 2832 (8.0M), S: 2000 x 2000 (4.0M)
Image Quality Modes
RAW, RAW & JPEG (Extra fine, Fine, Standard), JPEG (Extra fine, Fine, Standard)
Image Size (pixels) [16:9]
L: 6000 x 3376 (20 M), M: 4240 x 2400 (10 M), S: 3008 x 1688 (5.1 M)
Image Size (pixels) [3:2]
L: 6000 x 4000 (24M), M: 4240 x 2832 (12M), S: 3008 x 2000 (6.0M)
Image Size (pixels) [Sweep Panorama]
Wide: horizontal 12,416 x 1,856 (23M), vertical 5,536 x 2,160 (12M), Standard: horizontal 8,192 x 1,856 (15M), vertical 3,872 x 2,160 (8.4M)
Picture Effect
13 types: Posterization (Color), Posterization (B/W), Pop Color, Retro Photo, Partial Color (R/G/B/Y), High Contrast Monochrome, Toy Camera (Normal/Cool/Warm/Green/Magenta), Soft High-key, Soft Focus (High/Mid/Low), HDR Painting (High/Mid/Low), Rich-tone Monochrome, Miniature (Auto/Top/Middle (H)/Bottom/Right/Middle (V)/Left), Watercolor, Illustration (High/Mid/Low)
Recording Format
JPEG (DCF Ver. 2.0, Exif Ver.2.31, MPF Baseline compliant), RAW (Sony ARW 2.3 format)
Power
Supplied Battery
One rechargeable battery pack NP-FW50
Battery Life (Movie, actual recording)
Approx. 70 min (Viewfinder) / Approx. 75 min (LCD monitor) (CIPA standard)
Battery Life (Movie, continuous recording)
Approx. 125 min (Viewfinder) / Approx. 125 min (LCD monitor) (CIPA standard)
Battery Life (Still Images)
Approx. 380 shots (Viewfinder) / Approx. 420 shots (LCD monitor) (CIPA standard)
External Power
AC Adapter AC-PW20 (sold separately)
Internal Battery Charge
Yes
Power consumption with LCD screen
Still images: approx. 2.1 W (with E PZ 16-50 mm F3.5-5.6 OSS lens attached), Movies: approx. 3.5 W (with E PZ 16-50 mm F3.5-5.6 OSS lens attached)
Power consumption with Viewfinder
Still images: approx. 2.3 W (with E PZ 16–50 mm F3.5–5.6 OSS lens attached), Movies: approx. 3.5 W (with E PZ 16-50 mm F3.5-5.6 OSS lens attached)
Playback
Modes
Single (with or without shooting information Y RGB histogram & highlight/shadow warning), 12/30-frame index view, Enlarged display mode (L: 16.7x, M: 11.8x, S: 8.3x, Panorama [Standard]: 19.2x, Panorama [Wide]: 29.1x), Auto Review (10/5/2 seconds, Off), Image orientation (Manual/Off selectable), Slideshow, Panorama scrolling, Folder selection (Date/Still/AVCHD/XAVC S HD/XAVC S 4K), Forward/Rewind (movie), Delete, Protect, Rating, Display as Group
Other Features
Clear Image Zoom
Still images: Approx. 2x, Movies: Approx. 1.5x (4K), Approx. 2x (HD)
Digital Zoom
Smart zoom (Still images): M: Approx. 1.4x, S: Approx. 2x, Digital zoom (Still images): L: Approx. 4x, M: Approx. 5.7x, S: Approx. 8x, Digital zoom (Movie): Approx. 4x
Face Detection
Modes: Face Priority in AF (On/Off), Face Priority in Multi Metering (On/Off), Regist. Faces Priority (On/Off), Face Registration, Max. number of detectable: 8 faces
Others
Interval Recording (1–60-second interval, 1–9,999 shots, AE lock/AE tracking (High/Mid/Low)), Smile Shutter: Smile Shutter (selectable from 3 steps), Touch Shutter, Touch Focus: Yes (Touch Focus/Touch Pad/Touch Tracking), Bright Monitoring, Help guide, Area Setting, Shop Front Mode, Auto Object Framing (still images)
PlayMemories Camera Apps™
-
Self-Portrait Self-Timer
Yes
LCD Screen
Adjustable Angle
Up by approx. 180 degrees, Down by approx. 74 degrees
Brightness Control
Manual (5 steps between -2 and +2), Sunny Weather mode
Display Content
Graphic Display, Display All Info, No Disp. Info, Histogram, For viewfinder, Monitor Off
Focus Magnifier
Yes Focus Magnifier (5.9x, 11.7x)
Monitor Type
2.95 in (3.0-type) wide type TFT
Number of Dots
921,600 dots
Others
WhiteMagic, Grid Line, (Rule of 3rds Grid/Square Grid/Diag. + Square Grid/Off), Movie Marker, (Center/Aspect/Safety Zone/Guideframe)
Peaking MF
Yes (Level setting: High/Mid/Low/Off, Color: Red/Yellow/Blue/White)
Real-time Image Adjustment Display (LCD)
On/Off
Zebra
Yes (selectable level + range or lower limit as custom setting)
Interface
HD Output
HDMI micro connector (Type-D), BRAVIA Sync (Control for HDMI), PhotoTV HD, 4K movie output/4K still image PB
Bluetooth®
Yes (Bluetooth Standard Ver. 4.1 (2.4 GHz band))
Mic Terminal
Yes (3.5 mm Stereo minijack)
Multi/Micro USB terminal
Yes
NFC™
Yes (NFC forum Type 3 Tag compatible),One-touch remote, One-touch sharing
PC Interface
Mass-storage, MTP, PC remote
Wireless LAN (Built-In)
Yes (Wi-Fi Compatible, IEEE 802.11b/g/n (2.4 GHz band)), View on Smartphone, Remote control via Smartphone, Send to Computer, View on TV
Focus
Focus Area
Wide (425 points (phase-detection AF), 425 points (contrast-detection AF)) / Zone / Center / Flexible Spot (S/M/L) / Expanded Flexible Spot / Tracking (Wide / Zone / Center / Flexible Spot (S/M/L) / Expanded Flexible Spot)
Focus Mode
AF-A (Automatic AF), AF-S (Single-shot AF), AF-C (Continuous AF), DMF (Direct Manual Focus), Manual Focus
Focus Type
Fast Hybrid AF (phase-detection AF/contrast-detection AF)
AF illuminator
Yes (with built-in LED type)
AF Illuminator range
Approx. 0.3 – approx. 3.0 m (with E PZ 16-50 mm F3.5-5.6 OSS lens attached)
FOCUS POINT
425 points (phase-detection AF) / 425 points (contrast-detection AF)
Focus Sensitivity Range
EV-2 to EV 20 (ISO 100 equivalent with F2.0 lens attached)
Focus Sensor
Exmor® CMOS sensor
Focus type with LA-EA3 (Sold separately)
phase-detection
Other Features
Eye-start AF (only with LA-EA2 or LA-EA4 attached (Sold separately)), Object Tracking, EYE AF [Still images] (Human(Right/Left Eye Select) / Animal, AF micro adjustment (only with LA-EA2 or LA-EA4 attached (Sold separately)), Predictive control, Focus lock
Flash Control
External Flash Compatibility
Sony α System Flash compatible with Multi Interface Shoe, attach the shoe adapter for flash compatible with Auto-lock accessory shoe
Flash Bracketing
3/5 frames selectable. With 3 frames, in 1/3, 1/2, 2/3, 1.0, 2.0, or 3.0 EV increments. With 5 frames, in 1/3, 1/2, 2/3 EV increments.
Flash compensation
+/- 3.0 EV (switchable between 1/3 and 1/2 EV steps)
Flash Modes
Flash off, Autoflash, Fill-flash, Slow Sync., Rear Sync., Red-eye reduction (on/off selectable), Wireless control, Hi-speed sync
Flash coverage
16 mm (focal-length printed on the lens body)
Guide No.
6 (in meters at ISO 100)
Recycling Time
Approx. 4 sec
Wireless Control
Yes (Light signal: Available with Fill-flash, Slow Sync., Hi-speed sync. /Radio signal: Available with Fill-flash, Rear Sync., Slow Sync., Hi-speed sync.)
Exposure
Exposure Compensation
+/- 5.0 EV (1/3 EV, 1/2 EV steps selectable)
AE Lock
Locked when shutter button is pressed halfway. Available with AE lock button. (On/Off/Auto)
Exposure Bracketing
Bracket: Cont., Bracket: Single, 3/5 frames selectable. With 3 frames, in 1/3, 1/2, 2/3, 1.0, 2.0, or 3.0 EV increments. With 5 frames, in 1/3, 1/2, 2/3 EV increments.
EXPOSURE MODES
AUTO (iAuto/Superior Auto), Programmed AE (P), Aperture priority (A), Shutter-speed priority (S), Manual (M), Movie (Programmed AE (P) / Aperture priority (A) / Shutter-speed priority (S) / Manual (M) ), Slow & quick motion (Programmed AE (P) / Aperture priority (A) / Shutter-speed priority (S) / Manual (M) ), Sweep panorama, Scene selection
ISO Sensitivity (Recommended Exposure Index)
Still images: ISO 100–32000 (ISO numbers up to ISO 51200 can be set as expanded ISO range.), AUTO (ISO 100–6400, selectable lower limit and upper limit), Movies: ISO 100-32000 equivalent, AUTO (ISO 100-6400, selectable lower limit and upper limit)
Metering Mode
Multi-segment, Center-weighted, Spot
METERING SENSITIVITY
EV-2 to EV20 (at ISO100 equivalent with F2.0 lens attached)
Metering Sensor
Exmor® CMOS sensor
Metering Type
1200-zone evaluative metering
Scene Selection
Portrait, Sports Action, Macro, Landscape, Sunset, Night Scene, Hand-Held Twilight, Night Portrait, Anti Motion Blur
Drive
Self-timer
10 sec delay/5 sec delay/2 sec delay/Continuous self-timer (3 frames after 10 sec delay/5 frames after 10 sec delay/3 frames after 5 sec delay/5 frames after 5 sec delay/3 frames after 2 sec delay/5 frames after 2 sec delay)/Bracketing self-timer (Off/2 sec delay/5 sec delay/10sec delay)
Continuous Drive Speed (approx. max.)
Continuous shooting: Hi+: 11 fps, Hi: 8 fps, Mid: 6 fps, Lo: 3 fps
DRIVE MODES
Single Shooting, Continuous shooting (Hi+/Hi/Mid/Lo selectable), Self-timer, Self-timer (Cont.), Bracket: Single, Bracket: Cont., White Balance bracket, DRO bracket
No. of recordable frames (approx.)
JPEG Extra fine L: 76 frames, JPEG Fine L: 77 frames, JPEG Standard L: 77 frames, RAW: 33 frames, RAW & JPEG: 31 frames
Pixel Shift Multi Shooting
-
