Shutter
Electronic Front Curtain Shutter
Yes
Flash Sync. Speed
(Mechanical shutter), (Flash Sync. Priority) is (ON) or (AUTO):1/400 s (35 mm full frame), 1/500 s (APS-C), (Flash Sync. Priority) is (OFF):1/320 s (35 mm full frame), 1/400 s (APS-C), (Electrical shutter), 1/200 s (35 mm full frame), 1/250 s (APS-C)
SHUTTER SPEED
Still images, Single shot Mechanical Shutter: 1/8000 to 30 s, Bulb; AUTO: 1/32000 to 30 s, Bulb; Electronic Shutter: 1/32000 to 30 s; Still images, Continuous shooting Mechanical; Shutter: 1/8000 to 30 s; AUTO: 1/32000 to 1/2 s; Electronic Shutter: 1/32000 to 1/2 s; Movies: 1/8000 to 1/4 (1/3 steps), up to 1/60 in AUTO mode (up to 1/30 in Auto slow shutter mode)
Silent Shooting
Yes (ON/OFF)
type
Electronically controlled, vertical-traverse, focal-plane type
Shutter Type
Mechanical shutter/Electronic shutter
Recording (movie)
Audio Recording Format
LPCM 2ch(48 kHz 16bit), LPCM 2ch(48 kHz 24bit), LPCM 4ch(48 kHz 24bit), MPEG-4 AAC-LC 2ch
Color Space
Rec. ITU-R BT.2100 standard compatible (BT.2020 gamut)
Movie Functions
Audio Level Display, Audio Rec Level, PAL/NTSC Selector, Proxy Recording (1280 x 720 [6 Mbps], 1920 x 1080 [9 Mbps], 1920 x 1080 [16 Mbps]), TC/UB, Auto Slow Shutter, Gamma Disp. Assist, RAW Output(HDMI)
Picture Profile
Yes (Off / PP1-PP11) Parameters: Black level, Gamma (Movie, Still, S-Cinetone, Cine1-4, ITU709, ITU709 (800%), S-Log2, S-Log3, HLG, HLG1-3), Black Gamma, Knee, Color Mode, Saturation, Color Phase, Color Depth, Detail, Copy, Reset
Recording Format
XAVC S, XAVC HS
Slow & quick motion (shooting frame rate)
NTSC mode: 1fps, 2fps, 4fps, 8fps, 15fps, 30fps, 60fps, 120fps, 240fps, PAL mode: 1fps, 2fps 3fps, 6fps, 12fps, 25fps, 50fps, 100fps, 200fps* details of frame rate
Video Compression
XAVC S: MPEG-4 AVC/H.264, XAVC HS: MPEG-H HEVC/H.265
MOVIE RECORDING SYSTEM (XAVC S 4K)
3840 x 2160 (4:2:0, 8bit, NTSC) (Approx.): 120p (200 Mbps), 60p (150 Mbps), 30p (100 Mbps / 60 Mbps), 24p (100 Mbps / 60 Mbps); 3840 x 2160 (4:2:0, 8bit, PAL) (Approx.): 100p (200 Mbps), 50p (150 Mbps), 25p (100 Mbps / 60 Mbps); 3840 x 2160 (4:2:2, 10bit, NTSC) (Approx.): 120p (280 Mbps), 60p (200 Mbps), 30p (140 Mbps), 24p (100 Mbps); 3840 x 2160 (4:2:2, 10bit, PAL) (Approx.): 100p (280 Mbps), 50p (200 Mbps), 25p (140 Mbps)* details of frame rate
MOVIE RECORDING SYSTEM (XAVC S HD)
1920 x 1080 (4:2:0, 8bit, NTSC) (Approx.): 120p (100 Mbps / 60 Mbps), 60p (50 Mbps / 25 Mbps), 30p (50 Mbps / 16 Mbps), 24p (50 Mbps); 1920 x 1080 (4:2:0, 8bit, PAL) (Approx.): 100p (100 Mbps / 60 Mbps), 50p (50 Mbps / 25 Mbps), 25p (50 Mbps / 16 Mbps); 1920 x 1080 (4:2:2, 10bit, NTSC) (Approx.): 60p (50 Mbps), 30p (50 Mbps), 24p (50 Mbps); 1920 x 1080 (4:2:2, 10bit, PAL) (Approx.): 50p (50 Mbps), 25p (50 Mbps)* details of frame rate
Creative Look
ST, PT, NT, VV, VV2, FL, IN, SH, BW, SE, Custom Look (1-6)
MOVIE RECORDING SYSTEM (XAVC HS 4K)
3840 x 2160 (4:2:0, 10bit, NTSC) (Approx.): 120p (200 Mbps), 60p (150 Mbps / 75 Mbps / 45 Mbps), 24p (100 Mbps / 50 Mbps / 30 Mbps); 3840 x 2160 (4:2:0, 10bit, PAL) (Approx.): 100p (200 Mbps), 50p (150 Mbps / 75 Mbps / 45 Mbps); 3840 x 2160 (4:2:2, 10bit, NTSC) (Approx.): 120p (280 Mbps), 60p (200 Mbps / 100 Mbps), 24p (100 Mbps / 50 Mbps); 3840 x 2160 (4:2:2, 10bit, PAL) (Approx.): 100p (280 Mbps), 50p (200 Mbps / 100 Mbps)* details of frame rate
MOVIE RECORDING SYSTEM (XAVC HS 8K)
7680 x 4320 (4:2:0, 10bit, NTSC) (Approx.): 30p (400 Mbps / 200 Mbps), 24p (400 Mbps / 200 Mbps), 7680 x 4320 (4:2:0, 10bit, PAL) (Approx.): 25p (400 Mbps / 200 Mbps)* details of frame rate
MOVIE RECORDING SYSTEM (XAVC S-I 4K)
3840 x 2160 (4:2:2, 10bit, NTSC) (Approx.): 60p (600 Mbps), 30p (300 Mbps), 24p (240 Mbps); 3840 x 2160 (4:2:2, 10bit, PAL) (Approx.): 50p (500 Mbps), 25p (250 Mbps)* details of frame rate
MOVIE RECORDING SYSTEM (XAVC S-I HD)
1920 x 1080 (4:2:2, 10bit, NTSC) (Approx.): 60p (222 Mbps), 30p (111 Mbps), 24p (89 Mbps); 1920 x 1080 (4:2:2, 10bit, PAL) (Approx.): 50p (185 Mbps), 25p (93 Mbps)* details of frame rate
Recording (still images)
Color Space
sRGB standard (with sYCC gamut), Adobe RGB standard and Rec. ITU-R BT.2100 standard (BT.2020 gamut).
Dynamic Range Functions
Off, Dynamic Range Optimizer
IMAGE SIZE (PIXELS) [1:1]
35 mm full frame L: 5760 x 5760 (33M), M: 3744 x 3744 (14M), S: 2880 x 2880 (8.2M), APS-C M: 3744 x 3744 (14M), S: 2880 x 2880 (8.2M)
Image Quality Modes
RAW (Compressed / Lossless Compressed / Uncompressed), JPEG (Extra fine / Fine / Standard / Light), HEIF (4:2:0 / 4:2:2) (Extra fine / Fine / Standard / Light)
Image Size (pixels) [16:9]
35 mm full frame L: 8760 x 4864 (42M), M: 5616 x 3160 (17.7M), S: 4320 x 2432 (10.5M), APS-C M: 5616 x 3160 (17.7M), S: 4320 x 2432 (10.5M)
Image Size (pixels) [3:2]
35 mm full frame L: 8640 x 5760 (49.7M), M: 5616 x 3744 (21M), S: 4320 x 2880 (12.4M), APS-C M: 5616 x 3744 (21M), S: 4320 x 2880 (12.4M)
Picture Profile
Yes (Off / PP1-PP11) Parameters: Black level, Gamma (Movie, Still, S-Cinetone, Cine1-4, ITU709, ITU709 (800%), S-Log2, S-Log3, HLG, HLG1-3), Black Gamma, Knee, Color Mode, Saturation, Color Phase, Color Depth, Detail, Copy, Reset
Recording Format
JPEG (DCF Ver. 2.0, Exif Ver. 2.32, MPF Baseline compliant), HEIF (MPEG-A MIAF compliant), RAW (Sony ARW 4.0 format compliant)
IMAGE SIZE (PIXELS) [4:3]
35 mm full frame L: 7680 x 5760 (44.2M), M: 4992 x 3744 (18.6M), S: 3840 x 2880 (11M), APS-C M: 4992 x 3744 (18.6M), S: 3840 x 2880 (11M)
Creative Look
ST, PT, NT, VV, VV2, FL, IN, SH, BW, SE, Custom Look (1-6)
Other Features
Clear Image Zoom
Still images: Approx. 2x, Movies: Approx. 1.5x (4K), Approx. 2x (HD)
Digital Zoom
Smart zoom (Still images):35 mm full frame: M: Approx. 1.5x, S: Approx. 2x, APS-C: S: Approx. 2x, Digital zoom (still images): 35 mm full frame: L: Approx. 4x, M: Approx. 6.1x, S: Approx. 8x, APS-C: M: approx. 4x, S: approx. 5.2x, Digital zoom (Movie):35 mm full frame: Approx. 4x, APS-C: Approx. 4x
Face Detection
Face/Eye Priority in AF, Face Priority in Multi Metering, Regist. Faces Priority
Others
Interval Recording, ISO AUTO Min. SS, Bright Monitoring, Copyright Info, Set File Name, Save/Import Settings, Help guide, Video Light Mode, Zoom Ring Rotate
PlayMemories Camera Apps™
-
Self-Portrait Self-Timer
-
Interface
Bluetooth®
Yes (Bluetooth Standard Ver. 5.0 [2.4 GHz band])
Multi Interface Shoe
Yes (with Digital Audio Interface)
Headphone Terminal
Yes (3.5 mm Stereo minijack)
Mic Terminal
Yes (3.5 mm Stereo minijack)
Multi/Micro USB terminal
Yes (SuperSpeed USB 10 Gbps (USB 3.2) compatible)
PC Interface
Mass-storage / MTP
Vertical Grip Connector
Yes
Wireless LAN (Built-In)
Yes (Wi-Fi Compatible, IEEE 802.11a/b/g/n/ac [2.4-GHz band/5-GHz band])
LAN Terminal
Yes (1000BASE-T, 100BASE-TX, 10BASE-T)
Functions
FTP Transfer Func. (Wired LAN, USB Tethering, Wi-Fi)., View on Smartphone, Remote control via Smartphone, One-touch NFC remote, PC Remote, BRAVIA Sync (Control for HDMI), PhotoTV HD
Focus
Focus Area
Wide / Zone / Center / Flexible Spot / Expanded Flexible Spot / Tracking
Focus Mode
AF-S (Single-shot AF), AF-C ( Continuous AF), DMF (Direct Manual Focus), Manual Focus
Focus Type
Fast Hybrid AF (phase-detection AF / contrast-detection AF)
AF illuminator
Yes (with built-in LED type)
AF Illuminator range
Approx. 0.98 ft – approx. 0.98 ft (with FE 28-70 mm F3.5–5.6 OSS lens attached)
FOCUS POINT
35 mm full frame: 759 points (phase-detection AF), APS-C mode with FF lens: 759 points (phase-detection AF), with APS-C lens: 575 points (phase-detection AF) / 425 points (contrast-detection AF)
Focus Sensitivity Range
EV-4 to EV20 (ISO 100 equivalent with F2.0 lens attached)
Focus Sensor
Exmor RS CMOS sensor
Focus type with LA-EA3 (Sold separately)
Phase-detection
Other Features
Predictive control, Focus lock, AF Track Sens. (Still), AF Subj. Shift Sensitivity (Movie), AF Transition Speed (Movie), Switch V/H AF Area, AF Area Regist., Circ. of Focus Point
EYE AF
Still images: Human (Right/Left Eye Select) / Animal (Right/Left Eye Select) / Bird, Movie: Human (Right/Left Eye Select)
Exposure
Exposure Compensation
+/- 5.0EV (1/3 EV, 1/2 EV steps selectable) (with exposure compensation dial: +/- 3EV [1/3 EV steps])
AE Lock
Locked when shutter button is pressed halfway. Available with AE lock button. (On/Off/Auto)
Exposure Bracketing
Bracket: Cont., Bracket: Single, 3/5/9 frames selectable. (Ambient light, Flash light)
EXPOSURE MODES
AUTO(iAuto), Programmed AE (P), Aperture priority (A), Shutter-speed priority (S), Manual (M), Movie (Programmed AE (P) / Aperture priority (A) / Shutter-speed priority (S) / Manual (M) / Flexible Exp. Mode), Slow & Quick Motion (Programmed AE (P) / Aperture priority (A) / Shutter-speed priority (S) / Manual (M) / Flexible Exp. Mode)
ISO Sensitivity (Recommended Exposure Index)
Still images: ISO 100–32000 (ISO numbers up from ISO 50 to ISO 102400 can be set as expanded ISO range.), AUTO (ISO 100–12800, selectable lower limit and upper limit), Movies: ISO 100–32000 equivalent, AUTO (ISO 100–12800, selectable lower limit and upper limit)
Metering Mode
Multi-segment, Center-weighted, Spot, Spot Standard/Large, Entire Screen Avg., Highlight
METERING SENSITIVITY
EV -3 to EV 20 (at ISO100 equivalent with F2.0 lens attached)
Metering Sensor
Exmor RS CMOS sensor
Metering Type
1200-zone evaluative metering
Drive
Self-timer
10-sec. delay / 5-s delay / 2-s delay / Continuous self-time / Bracketing self-timer
Continuous Drive Speed (approx. max.)
AUTO/Electronic Shutter: Continuous shooting: Hi+: 30fps, Hi: 20fps, Mid: 15fps, Lo: 5fps, Mechanical Shutter: Continuous shooting: Hi+: 10fps, Hi: 8fps, Mid: 6fps, Lo: 3fps
DRIVE MODES
Single Shooting, Continuous shooting (Hi+/Hi/Mid/Lo selectable), Self-timer, Self-timer (Cont.), Bracket: Single, Bracket: Cont., White Balance bracket, DRO bracket
No. of recordable frames (approx.)
JPEG Extra fine L: 182 frames, JPEG Fine L: 400 frames, JPEG Standard L: 400 frames, RAW: 238 frames, RAW & JPG: 192 frames, RAW (Lossless Compression): 96 frames, RAW (Lossless Compression) & JPG: 83 frames, RAW (Uncompressed): 82 frames, RAW (Uncompressed) & JPG: 78 frames
Pixel Shift Multi Shooting
Yes (4 shots / 16 shots)
