Recording System
Location information Link from smartphone
Yes
Media
SD memory card, SDHC memory card (UHS-I/II compliant), SDXC memory card (UHS-I/II compliant), microSD memory card, microSDHC memory card, microSDXC memory card
Memory Card Slot
SLOT1: Slot for SD (UHS-I/II compliant) memory card, SLOT2: Slot for SD (UHS-I/II compliant) memory card
Recording mode on 2 memory cards
Simult. Rec (Still), Simult. Rec (Movie), Simult. Rec (Still/Movie), Sort (JPEG/RAW), Sort (Still/Movie), Auto Switch Media (On/Off), Copy
Viewfinder
Viewfinder Type
0.51 inch (0.5 type) electronic viewfinder (color), Quad-VGA OLED
Diopter adjustment
-4.0 to +3.0 m-1
Eye Point
Approx. 23 mm from the eyepiece lens, 18.5 mm from the eyepiece frame at -1m-1 (CIPA standard)
Magnification
approx. 0.78 x (with 50mm lens at infinity, -3.28 feet-1)
Brightness Control (Viewfinder)
Auto/Manual (5 steps between -2 and +2)
Color Temperature Control
Manual (5 steps)
Display Contents
Graphic Display, Display All Info, No Display Info, Digital Level Gauge, Histogram
Finder Frame Rate Selection
STD 60fps / HI 120fps
Number of Dots
3 686 400 dots
Shutter
Electronic Front Curtain Shutter
Yes (ON/OFF)
Flash Sync. Speed
1/250 sec.
SHUTTER SPEED
[Still images, Single shot] Mechanical Shutter: 1/8000 to 30 sec, Bulb, AUTO: 1/32000 to 30 sec, Bulb, Electronic Shutter: 1/32000 to 30 sec, [Still images, Continuous shooting] Mechanical Shutter: 1/8000 to 30 sec, AUTO: 1/32000 to 1/8 sec, Electronic Shutter: 1/32000 to 1/8 sec, [Movies]: 1/8000 to 1/4 (1/3 steps) up to 1/60 in AUTO mode (up to 1/30 in Auto slow shutter mode)
Silent Shooting
Yes (Electronic Shutter)
type
Electronically controlled, vertical-traverse, focal-plane type
Shutter Type
Auto/Mechanical shutter/Electronic shutter
Recording (movie)
Audio Recording Format
XAVC S: LPCM 2ch, AVCHD: Dolby® Digital (AC-3) 2ch, Dolby® Digital Stereo Creator
Color Space
xvYCC standard (x.v.Color when connected via HDMI cable) compatible with TRILUMINOS Color
Creative Style
Standard, Vivid, Neutral, Clear, Deep, Light, Portrait, Landscape, Sunset, Night Scene, Autumn leaves, Black & White, Sepia, Style Box (1-6), (Contrast (-3 to +3 steps), Saturation (-3 to +3 steps), Sharpness (-5 to +5 steps))
HDMI OUTPUT
3840 x 2160 (25p), 1920 x 1080 (50p), 1920 x 1080 (50i), 1920 x 1080 (24p), 1920 x 1080 (60p), 1920 x 1080 (60i), 3840 x 2160 (30p), 3840 x 2160 (24p), YCbCr 4:2:2 8 bit / RGB 8 bit
Image Size (pixels), NTSC
XAVC S 4K: 3840 x 2160 (30p, 100 M), 3840 x 2160 (24p, 100 M), 3840 x 2160 (30p, 60 M), 3840 x 2160 (24p, 60 M), XAVC S HD: 1920 x 1080 (120p, 100 M), 1920 x 1080 (120p, 60 M), 1920 x 1080 (60p, 50 M), 1920 x 1080 (30p, 50 M), 1920 x 1080 (24p, 50 M), 1920 x 1080 (60p, 25 M), 1920 x 1080 (30p, 16 M), AVCHD: 1920 x 1080 (60i, 24 M, FX), 1920 x 1080 (60i, 17 M, FH)
Image Size (pixels), PAL
XAVC S 4K: 3840 x 2160 (25p, 100 M), 3840 x 2160 (25p, 60 M), AVCHD: 1920 x 1080 (50i, 24 M, FX), 1920 x 1080 (50i, 17 M, FH)
Movie Functions
Audio Level Display, Audio Rec Level, Proxy Recording (1280 x 720 (Approx. 9 Mbps)), TC/UB (TC Preset/UB Preset/TC Format/TC Run/TC Make/UB Time Rec), Auto Slow Shutter, REC Control, Clean HDMI Info. (ON/OFF selectable)
Picture Effect
Posterization (Color), Posterization (B/W), Pop Color, Retro Photo, Partial Color (R/G/B/Y), High Contrast Monochrome, Toy Camera(Normal/Cool/Warm/Green/Magenta), Soft High-key
Recording Format
XAVC S, AVCHD format Ver. 2.0 compliant
Slow & quick motion (recording frame rate & image size)
NTSC mode: 1920x1080 (60p, 30p, 24p), PAL mode: 1920x1080 (50p, 25p)
Slow & quick motion (shooting frame rate)
NTSC mode: 1fps, 2fps, 4fps, 8fps, 15fps, 30fps, 60fps, 120fps, PAL mode: 1fps, 2fps, 3fps, 6fps, 12fps, 25fps, 50fps, 100fps,
Video Compression
XAVC S: MPEG-4 AVC/H.264, AVCHD: MPEG-4 AVC/H.264
Recording (still images)
Color Space
sRGB standard (with sYCC gamut) and Adobe RGB standard compatible with TRILUMINOS Color
Creative Style
Standard, Vivid, Neutral, Clear, Deep, Light, Portrait, Landscape, Sunset, Night Scene, Autumn leaves, Black & White, Sepia, Style Box (1-6), (Contrast (-3 to +3 steps), Saturation (-3 to +3 steps), Sharpness (-5 to +5 steps))
Dynamic Range Functions
Off, Dynamic Range Optimizer (Auto/Level (1-5)), Auto High Dynamic Range (Auto Exposure Difference, Exposure Difference Level (1-6 EV, 1.0 EV step))
IMAGE SIZE (PIXELS) [1:1]
35 mm full frame L: 4000 x 4000 (16M), M: 2624 x 2624 (6.9 M), S: 2000 x 2000 (4.0 M), APS-C L: 2624 x 2624 (6.9 M), M: 2000 x 2000 (4.0 M), S: 1312 x 1312 (1.7 M)
Image Quality Modes
RAW, RAW & JPEG (Extra fine, Fine, Standard), JPEG (Extra fine, Fine, Standard)
Image Size (pixels) [16:9]
35 mm full frame L: 6000 x 3376 (20 M), M: 3936 x 2216 (8.7M), S: 3008 x 1688 (5.1M), APS-C L: 3936 x 2216 (8.7M), M: 3008 x 1688 (5.1M), S: 1968 x 1112 (2.2M)
Image Size (pixels) [3:2]
35 mm full frame L: 6000 x 4000 (24M), M: 3936 x 2624 (10M), S: 3008 x 2000 (6.0M), APS-C L: 3936 x 2624 (10M), M: 3008 x 2000 (6.0M), S: 1968 x 1312 (2.6M)
Image Size (pixels) [Sweep Panorama]
-
Picture Effect
8 types: Posterization (Color), Posterization (B/W), Pop Color, Retro Photo, Partial Color (R/G/B/Y), High Contrast Monochrome, Toy Camera (Normal/Cool/Warm/Green/Magenta), Soft High-key, Rich-tone Monochrome
Recording Format
JPEG (DCF Ver. 2.0, Exif Ver.2.31, MPF Baseline compliant), RAW (Sony ARW 2.3 format)
IMAGE SIZE (PIXELS) [4:3]
35 mm full frame L: 5328 x 4000 (21 M), M: 3488 x 2624 (9.2 M), S: 2656 x 2000 (5.3 M) APS-C L: 3488 x 2624 (9.2 M), M: 2656 x 2000 (5.3 M), S: 1744 x 1312 (2.3 M)
Power
USB Power Supply
Yes (Available with Multi/Micro USB Terminal or USB Type-C Terminal)
Supplied Battery
One rechargeable battery pack NP-FZ100
Battery Life (Movie, actual recording)
Approx. 110 min (Viewfinder) / Approx. 120 min (LCD monitor) (CIPA standard)
Battery Life (Movie, continuous recording)
Approx. 195 min (Viewfinder) / Approx. 200 min (LCD monitor) (CIPA standard)
Battery Life (Still Images)
Approx. 500 shots (Viewfinder) / approx. 690 shots (LCD monitor) (CIPA standard)
Internal Battery Charge
Yes (Available with Multi/Micro USB Terminal or USB Type-C Terminal)
Power consumption with LCD screen
Still images: approx. 2.9 W (with FE 28–70 mm F3.5–5.6 OSS lens attached), Movies: Approx. 4.9W (with FE 28-70 mm F3.5-5.6 OSS lens attached)
Power consumption with Viewfinder
Still images: approx. 3.9 W (with FE 28-70 mm F3.5-5.6 OSS lens attached), Movies: Approx 5.0 W (with FE 28-70 mm F3.5-5.6 OSS lens attached)
Playback
Modes
Single (with or without shooting information Y RGB histogram & highlight/shadow warning), 9/25-frame index view, Enlarged display mode (L: 15.0x, M: 9.84x, S: 7.52x), Auto Review (10/5/2 sec, Off), Image orientation (Auto/Manual/Off selectable), Slideshow, Folder selection (Date/Still/MP4/AVCHD/XAVC S HD/XAVC S 4K), Forward/Rewind (movie), Delete, Protect, Rating, Display as Group, Voice Memo
Other Features
Clear Image Zoom
Still images: Approx. 2x, Movies: Approx. 1.5x (4K), Approx. 2x (HD)
Digital Zoom
Smart zoom (Still images):35mm full frame: M:approx 1.5x, S:approx 2x, APS-C: M:approx 1.3x, S:approx 2x, Digital zoom (Still images):35mm full frame: L:approx 4x, M:approx 6.1x, S:approx 8x, APS-C: L:approx 4x, M:approx 5.2x, S:approx 8x, Digital zoom (Movie):35mm full frame: approx 4x, APS-C: approx 4x
Face Detection
Modes: Face Priority in AF (On/Off), Face Priority in Multi Metering (On/Off), Regist. Faces Priority (On/Off), Face registration, Max. number detectable: 8 faces
Others
Interval Recording, Touch Focus: Yes (Touch Focus/Touch Pad/Touch Tracking), ISO AUTO Min. SS, Bright Monitoring, Copyright Info, Set File Name, FTP Transfer Func., Help guide, Area Setting, Shop Front Mode, Video Light Mode, Zoom Ring Rotate
PlayMemories Camera Apps™
-
Self-Portrait Self-Timer
-
LCD Screen
Adjustable Angle
Up by approx. 107 degrees, Down by approx. 41 degrees
Brightness Control
Manual (5 steps between -2 and +2), Sunny Weather mode
Display Content
Graphic Display, Display All Info, No Disp. Info, Digital Level Gauge, Histogram, For viewfinder, Monitor Off
Focus Magnifier
Yes (35mm full frame: 4.7x, 9.4x, APS-C: 3.1x, 6.2x)
Monitor Type
2.95 inch (3.0-type) wide type TFT
Number of Dots
1,440,000 dots
Others
WhiteMagic, Grid Line (Rule of 3rds Grid/Square Grid/Diag. + Square Grid/Off), Movie Marker (Center/Aspect/Safety Zone/Guideframe)
Peaking MF
Yes (Level setting: High/Mid/Low/Off, Color: Red/Yellow/Blue/White)
Real-time Image Adjustment Display (LCD)
On/Off
Zebra
Yes (selectable level + range or lower limit as custom setting)
Display Selecter (Finder/LCD)
Yes (Auto/Manual)
Interface
HD Output
HDMI micro connector (Type-D), BRAVIA Sync (Control for HDMI), PhotoTV HD, 4K movie output/4K still image PB
Bluetooth®
Yes (Bluetooth Standard Ver. 4.1 (2.4 GHz band))
Multi Interface Shoe
Yes (with Digital Audio Interface)
Headphone Terminal
Yes (3.5 mm Stereo minijack)
Mic Terminal
Yes (3.5 mm Stereo minijack)
Multi/Micro USB terminal
Yes
NFC™
Yes (NFC forum Type 3 Tag compatible), One-touch remote, One-touch sharing
PC Interface
Mass-storage, MTP, PC remote
Vertical Grip Connector
Yes
Wireless LAN (Built-In)
Wi-Fi Compatible, IEEE 802.11a/b/g/n/ac (2.4 GHz band/5 GHz band), View on Smartphone, Remote control via Smartphone, Send to Computer, View on TV
Smart Accessory Terminal 2
-
Auto-lock Accessory Shoe
-
LAN Terminal
Yes (1000BASE-T)
Focus
Focus Area
Wide (693 points (phase-detection AF), 425 points(contrast-detection AF)) / Zone / Center / Flexible Spot (S/M/L) /Expanded Flexible Spot/ Tracking (Wide / Zone / Center / Flexible Spot (S/M/L)/Expanded Flexible Spot)
Focus Mode
AF-S (Single-shot AF), AF-C (Continuous AF), DMF (Direct Manual Focus), Manual Focus
Focus Type
Fast Hybrid AF (phase-detection AF/contrast-detection AF)
AF illuminator
Yes (with built-in LED type)
AF Illuminator range
Approx. 0.3 m - approx. 3.0 m (with FE 28-70 mm F3.5-5.6 OSS attached)
FOCUS POINT
35 mm full frame: 693 points (phase-detection AF), APS-C mode with FF lens: 299 points (phase-detection AF), with APS-C lens: 221 points (phase-detection AF) / 425 points (contrast-detection AF)
Focus Sensitivity Range
EV-3 to EV 20 (ISO 100 equivalent with F2.0 lens attached)
Focus Sensor
Exmor RS CMOS sensor
Focus type with LA-EA3 (Sold separately)
phase-detection
Other Features
Eye-start AF (only with LA-EA2 or LA-EA4 attached (Sold separately)), Tracking, [Still images] Human (Right/Left Eye Select) / Animal, [Movie] Human (Right/Left Eye Select), AF micro adjustment with LA-EA2 or LA-EA4 (Sold separately), Predictive control, Focus lock, Swt.V/H AF Area, AF Area Regist., Circ. of Focus Point
Flash Control
External Flash Compatibility
Sony α System Flash compatible with Multi Interface Shoe, attach the shoe adapter for flash compatible with Auto-lock accessory shoe
Flash Bracketing
3/5/9 frames selectable. With 3 or 5 frames, in 1/3, 1/2, 2/3, 1.0, 2.0, 3.0 EV increments, with 9 frames, in 1/3, 1/2, 2/3, 1.0 EV increments.
Flash compensation
+/- 3.0 EV (switchable between 1/3 and 1/2 EV steps)
Flash Modes
Flash off, Autoflash, Fill-flash, Slow Sync., Rear Sync., Red-eye reduction (on/off selectable), Wireless, Hi-speed sync.
Wireless Control
Yes (Light signal: Available with Fill-flash, Slow Sync., Hi-speed sync. /Radio signal: Available with Fill-flash, Rear Sync., Slow Sync., Hi-speed sync.)
Exposure
Exposure Compensation
+/- 5.0EV (1/3 EV, 1/2 EV steps selectable) (with exposure compensation dial: +/- 3EV (1/3 EV steps))
AE Lock
Locked when shutter button is pressed halfway. Available with AE lock button. (On/Off/Auto)
Exposure Bracketing
Bracket: Cont., Bracket: Single, 3/5/9 frames selectable. With 3 or 5 frames, in 1/3, 1/2, 2/3, 1.0, 2.0, or 3.0 EV increments, with 9 frames, in 1/3, 1/2, 2/3, or 1.0 EV increments.
EXPOSURE MODES
AUTO (iAuto), Programmed AE (P), Aperture priority (A), Shutter-speed priority (S), Manual (M), Movie (Programmed AE (P) / Aperture priority (A) / Shutter-speed priority (S) / Manual (M) ), Slow & Quick Motion (Programmed AE (P) / Aperture priority (A) / Shutter-speed priority (S) / Manual (M))
ISO Sensitivity (Recommended Exposure Index)
[Still images] Mechanical Shutter: ISO 100-51200 (ISO numbers up from ISO 50 to ISO 204800 can be set as expanded ISO range), AUTO (ISO 100-12800, selectable lower limit and upper limit), Electronic Shutter: ISO 100-25600 (ISO numbers up from ISO 50 can be set as expanded ISO range), AUTO (ISO 100-12800, selectable lower limit and upper limit), [Movies] ISO 100-51200 equivalent (ISO numbers up to ISO 102400 can be set as expanded ISO range), AUTO (ISO 100-12800, selectable lower limit and upper limit)
Metering Mode
Multi-segment, Center-weighted, Spot, Spot Standard/Large, Entire Screen Avg., Highlight
METERING SENSITIVITY
EV -3 to EV 20 (at ISO100 equivalent with F2.0 lens attached)
Metering Sensor
Exmor RS CMOS sensor
Metering Type
1200-zone evaluative metering
Drive
Self-timer
10 sec delay/5 sec delay/2 sec delay/Continuous self-timer (3 frames after 10 sec delay/5 frames after 10 sec delay/3 frames after 5 sec delay/5 frames after 5 sec delay/3 frames after 2 sec delay/5 frames after 2 sec delay)/Bracketing self-timer (Off/2 sec delay/5 sec delay/10sec delay)
Continuous Drive Speed (approx. max.)
AUTO/Electronic Shutter: Continuous shooting: Hi: max. 20 fps, Mid: max. 10fps, Lo: max. 5fps , Mechanical Shutter: Continuous shooting: Hi: max. 10fps, Mid: max. 8fps, Lo: max. 3 fps
DRIVE MODES
Single Shooting, Continuous shooting (Hi/Mid/Lo selectable), Self-timer, Self-timer (Cont.), Bracket: Single, Bracket: Cont., White Balance bracket, DRO bracket
No. of recordable frames (approx.)
JPEG Extra fine L: 361 frames, JPEG Fine L: 361 frames, JPEG Standard L: 361 frames, RAW: 239 frames, RAW & JPG: 226 frames, RAW (Uncompressed): 131 frames, RAW (Uncompressed) & JPG: 120 frames
